Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105, Tiagra -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 525 chromoly touring frame
Suspension Fork
Lightweight aluminum touring fork w/disc tabs
Drivetrain
Rear Derailleur
Shimano 105 RD-5600 GS Silver
Front Derailleur
Shimano Tiagra FD-4503 Silver
Shift Levers
Shimano Tiagra ST-4500 Silver
Cassette
SRAM PG-950 11-26T 9 speed
Crank
Shimano Tiagra FC-4503 50/39/30 Silver
Bottom Bracket
Shimano HolloTech II
Chain
KMC HG-73
Pedals
Shimano PD-M520 Silver
Wheels
Front Hub
Shimano LX HB-T660 Silver 36hole
Rear Hub
Shimano LX FH-T660 Silver 36hole
Rims
Mavic A319 Silver 36 hole
Spokes
Silver butted spokes w/brass nipples
Tires
Continental Contact w/Reflex 700x28c
Brakes
Brakes
Shimano BR-R550 cantilever silver
Brake Levers
Shimano Tiagra ST-4500 Silver
Cockpit
Stem
Norco lightweight 3D forged - Silver
Handlebar
Norco 6061 alloy road bar - Silver
Grips
Wrap - Brown w/gel
Headset
FSA No.18 Cartridge - Silver
Seat
Saddle
Norco comfort touring saddle
Seatpost
Norco lateral clamping seatpost - Silver
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 608 mm | 608 mm | 618 mm | 638 mm |
| Top Tube Length | 532 mm | 542 mm | 557 mm | 587 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 495 mm | 546 mm | 596 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1041 mm | 1042 mm | 1052 mm | 1072 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 746 mm | 771 mm | 804 mm | 838 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Cabot completes the Norco Cabot model. Norco launched 7 bikes of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Touring bikes
According to our calculations, the average cost of a Touring bike that is reliable is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2010 for 1299$. If we compare this with the average Touring bike cost we notice that the price is 29% more expensive.
Cabot components
Fork material
Cabot has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The wheels on Cabot are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Cabot comes with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
