Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset Altus -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano STEPS E8035 Downtube -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum Frame, Fender Mounts, Rack Mounts, Bottle Mount
Suspension Fork
SR Suntour XCM32 DS, 120mm Travel, E-Bike
Drivetrain
Rear Derailleur
Shimano Altus M-2000
Shift Levers
Shimano Altus SL-M2010
Cassette
Shimano Acera CS-HG2009, 11/36T, 9 Speed
Crank
Prowheel E8000, 170mm, 34T
Chain
KMC e9S E-Bike
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy 15x110mm Boost, 6 Bolt
Rear Hub
Alloy 12x148mm Boost, HG, 6 Bolt
Rims
Alex MD25 TRS 29", 32H
Tires
WTB Ranger Comp 2.25"
Brakes
Brakes
Tektro HD-M285 Hydraulic, E-Bike
Brake Levers
Tektro HD-M285
Disk Rotors
Tektro 180mm
Cockpit
Stem
Alloy, 60mm Length, 31.8mm Clamp
Handlebar
Butted 6061 Alloy, 740mm, 20mm Rise
Grips
VP Lock-On
Headset
FSA No.57E Sealed Bearing
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18 Dropper, 31.6mm, 130mm
Motor & Battery
Motor
Shimano STEPS E7000
Battery
Shimano STEPS E8035 Downtube
Remote
Shimano STEPS E7000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.66 mm | 1.54 mm | 1.46 mm | 1.38 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 675 mm | 705 mm | 739 mm | 772 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 107 mm | 107 mm | 107 mm | 107 mm |
| Stack | 625 mm | 625 mm | 635 mm | 645 mm |
| Reach | 376 mm | 406 mm | 436 mm | 466 mm |
| Top Tube Length | 560 mm | 591 mm | 623 mm | 656 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1116 mm | 1146 mm | 1180 mm | 1213 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 53 mm | 53 mm |
| Standover Height | 663 mm | 694 mm | 723 mm | 750 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Charger VLT completes the Norco E Charger model. 2 e-bikes variations carry this model name so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3399$. Comparing this to the average Trail e-bike price, we see that the price is 1.01% higher.
Overview of components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Norco Charger VLT 2020, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Charger VLT comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Norco model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
