Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset Altus -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano STEPS E8035 Downtube -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum Frame, Fender Mounts, Rack Mounts, Bottle Mount
Suspension Fork
SR Suntour XCM32 DS, 120mm Travel, E-Bike
Drivetrain
Rear Derailleur
Shimano Altus M-2000
Shift Levers
Shimano Altus SL-M2010
Cassette
Shimano Acera CS-HG2009, 11/36T, 9 Speed
Crank
Prowheel E8000, 170mm, 34T
Chain
KMC e9S E-Bike
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy 15x110mm Boost, 6 Bolt
Rear Hub
Alloy 12x148mm Boost, HG, 6 Bolt
Rims
Alex MD25 TRS 29", 32H
Tires
WTB Ranger Comp 2.25"
Brakes
Brakes
Tektro HD-M285 Hydraulic, E-Bike
Brake Levers
Tektro HD-M285
Disk Rotors
Tektro 180mm
Cockpit
Stem
Alloy, 60mm Length, 31.8mm Clamp
Handlebar
Butted 6061 Alloy, 740mm, 20mm Rise
Grips
VP Lock-On
Headset
FSA No.57E Sealed Bearing
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18 Dropper, 31.6mm, 130mm
Motor & Battery
Motor
Shimano STEPS E7000
Battery
Shimano STEPS E8035 Downtube
Remote
Shimano STEPS E7000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.66 mm | 1.54 mm | 1.46 mm | 1.38 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 675 mm | 705 mm | 739 mm | 772 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 107 mm | 107 mm | 107 mm | 107 mm |
| Stack | 625 mm | 625 mm | 635 mm | 645 mm |
| Reach | 376 mm | 406 mm | 436 mm | 466 mm |
| Top Tube Length | 560 mm | 591 mm | 623 mm | 656 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1116 mm | 1146 mm | 1180 mm | 1213 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 53 mm | 53 mm |
| Standover Height | 663 mm | 694 mm | 723 mm | 750 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
Model Overview
Charger VLT completes the Norco E Charger model. There are 2 e-bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3999$. If we compare this with the average Trail e-bike cost we notice that the price is 18.84% more expensive.
Overview of components
Fork
This e-bike has the SunTour XCM fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The Charger VLT 2021 e-bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Charger VLT has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 4 sizes. They vary from 154 cm – 191 cm (5.05 ft – 6.27 ft). In short, you can easily find one that suits you.
Dropper post
The Norco model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
