Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RST
-
Groupset Altus, Suntour SR -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Magnum 6061 Alloy Frame
Suspension Fork
RST DIRT 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus M-2000 9spd
Front Derailleur
N/A
Shift Levers
Shimano Altus SL-M2000 9spd
Cassette
Shimano Acera CS-HG2009 11/36 9spd
Crank
SR Suntour Zeron 30T
Bottom Bracket
SR Suntour BB24
Chain
KMC Z99 9spd
Chain Guide
N/A
Pedals
VP Nylon Flat Pedal
Wheels
Front Hub
Joytech D341DSE Alloy Disc QR
Rear Hub
Joytech D342TSE-HL Alloy Disc QR 9spd
Rims
WTB SX23 26"
Spokes
Stainless steel 14 gauge, black
Tires
Kenda Small Block Eight 26" x 2.25"
Brakes
Brakes
Tektro MD-280 Mech Disc w/160mm rotor
Brake Levers
Tektro Alloy
Cockpit
Stem
Norco Alloy 50mm
Handlebar
Norco 6061 double butted aAlloy 740mmx15mm
Grips
Norco Grip w/small flange
Headset
Zero Stack Headset
Seat
Saddle
Norco Dirt Saddle
Seatpost
Norco Alloy 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Short | Long |
|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.38 mm |
| Bottom Bracket Height | 325 mm | 325 mm |
| Front Center | 656 mm | 669 mm |
| Rake | 44 mm | 44 mm |
| Trail | 88 mm | 88 mm |
| Stack | 558 mm | 558 mm |
| Reach | 392 mm | 405 mm |
| Top Tube Length | 563 mm | 576 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 330 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° |
| Head Tube Length | 115 mm | 115 mm |
| Chainstay Length | 418 mm | 418 mm |
| Wheelbase | 1074 mm | 1087 mm |
| Bottom Bracket Drop | 15 mm | 15 mm |
| Standover Height | 736 mm | 732 mm |
| Front Travel | 100 mm | 100 mm |
| Wheels | 26" | 26" |
About this model
Magnum completes the Norco Magnum model. Norco released 7 bikes variations of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Dirt Jump bikes average price
If you want an acceptable Dirt Jump bike you should know that the average price is 863$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Dirt Jump bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Norco Magnum price was 649$. Doing a quick comparison, we notice that Magnum price is 32.97% lower than the average cost of a Dirt Jump bike.
Overview of components
Fork
The Magnum comes factory-installed with the RST fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the Magnum model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
