Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 20" -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full 4130 chromoly frame, integrated headtube, mid BB shell, compact dropout, removable U brake pivots
Suspension Fork
BMX Chromoly with 3/8” dropouts, no pivots
Rear Shock
N/A
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
9T one piece BMX cassette
Crank
Chromoly tubular 2 pc BMX cranks, 175 mm, with 25T ( 3 mm thickness ) Norco design w/ custom colour
Bottom Bracket
Mid BMX, sealed bearing, 2 pc axle design
Chain
KMC Z-410 CR MO silver
Pedals
Oddessey resin, yellow
Wheels
Front Hub
Alloy sealed bearing, 36 H, 3/8” axle
Rear Hub
Alloy, Japanese sealed bearing, hollow 14 mm axle, 9T
Rims
Alien Nation Deviant front painted, 440 rear Nickle Plated
Spokes
UCP plated spokes
Tires
Oddessey Akensen 20x1.9 rear, 20x2.25 front
Brakes
Brakes
Tektro FX-570C alloy U brake, custom colour
Brake Levers
Tektro XL-750 BMX lever, right side
Cockpit
Stem
Alloy BMX 4 bolt with custom front clamp, 50 ext
Handlebar
Cro-mo butted “big bar “ 8” rise, 711 mm, heat treated
Grips
Axiom rubber BMX grip with small flange,
Headset
VP A61 ACMF Campagnolo type integrated BMX
Seat
Saddle
Pivotal BMX, thin design with custom Norco graphic
Seatpost
Pivotal BMX alloy stubby post, 242 mm x 25.4 mm
Fit data
Geometry
Numbers for sizing and ride feel.
Model Overview
REV completes the Norco Rev model. 10 bikes variations carry this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
BMX bikes average price
Our math shows that the average cost of a dependable BMX bike is 348$. However, this doesn’t mean that if you spend less money on a BMX bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Norco REV price was 735$. In conclusion, this bike price is 111.21% more expensive than the price of the average BMX bike.
BMX bikes average weight
BMX bikes weigh an average of 10.54 kg (23.24 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Norco REV it’s weighing 10.9 kg (24.03 lbs). At this weight, is slightly heavier than average. In conclusion, the average BMX bike weighs 3.42% less than REV.
Overview of components
Fork material
REV has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The wheels on REV are the 20″ aluminum type. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The REV comes with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
