Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Fork RockShox Bluto RL
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sasquatch alloy frame w/ taper HT /suspension corrected geometry
Suspension Fork
Rockshox Bluto RL 100mm solo air 15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT RD-M 786 SGS 10 sp
Front Derailleur
Shimano SLX M660-E 10 speed E-Type
Shift Levers
Jagwire LEX housing
Cassette
Shimano Deore HG62 11-36T 10 sp
Crank
FSA Comet CK7156 36/22T w/guard
Bottom Bracket
FSA Mega Exo BB external 100mm
Chain
SRAM PC 1031 10 sp
Chain Tensioner
N/A
Pedals
Wellgo alloy body / alloy cage MTB pedal
Wheels
Front Hub
Novatec alloy 15x 150mm disc sealed bearing
Rear Hub
KT alloy 170mm disc w/QR sealed bearing
Rims
Aluminum 80mm, single wall rim w/holes
Tires
Vee Snow Shoe 26x4.5 folding bead (120 TPI)
Brakes
Brakes
SRAM Guide R 4 piston hydraulic w/ 160mm rotor
Brake Levers
SRAM Guide R
Disk Rotors
N/A
Cockpit
Stem
Alloy 3D forged MTB stem, 4 bolt front clamp
Handlebar
Norco 25 mm rise 740 mm width 6061 DB
Grips
Super light foam grip / all black
Headset
FSA No 42/ACB tapered
Seat
Saddle
Norco MTB XC Trail saddle w/chromoly rail
Seatpost
Norco Lite 3D forged double bolt 2014 alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm | 1.47 mm | 1.42 mm |
| Bottom Bracket Height | 313 mm | 313 mm | 313 mm | 313 mm |
| Front Center | 653 mm | 674 mm | 694 mm | 714 mm |
| Rake | 51 mm | 51 mm | 51 mm | 50 mm |
| Trail | 77 mm | 77 mm | 77 mm | 78 mm |
| Stack | 607 mm | 611 mm | 616 mm | 621 mm |
| Reach | 382 mm | 400 mm | 419 mm | 438 mm |
| Top Tube Length | 568 mm | 588 mm | 608 mm | 628 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1096 mm | 1116 mm | 1137 mm | 1157 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 718 mm | 720 mm | 724 mm | 744 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Sasquatch belongs to the Norco Sasquatch model. Norco released 16 bikes variations of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Fatbike bikes average price
If you want to purchase a solid Fatbike bike, it is important to know that the average cost is 1743$. However, you could also get a good Fatbike bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2475$. Doing a quick comparison, we notice that Sasquatch price is 42% more expensive than the average cost of a Fatbike bike.
Sasquatch components
Fork
Norco Sasquatch 2015 bike is equipped with the RockShox Bluto RL fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Sasquatch are the 26″ aluminum type. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Norco Sasquatch bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
