Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Alivio, Shimano -
Suspension Rigid -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano E8010 504Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
153cm - 163cm
MD
161cm - 171cm
LG
168cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Double Butted Alloy E-Bike Frame, Internal Cables
Suspension Fork
Alloy, Steel Steerer
Drivetrain
Rear Derailleur
Shimano Alivio RD-M4000
Shift Levers
Shimano Alivio SL-M4000
Cassette
Shimano Alivio CS-HG400, 11-36T, 9 Speed
Crank
Shimano FC-E6100, 38T, 170mm
Chain
KMC E9-Sport
Pedals
City Pedal, Kraton Traction Inlay
Wheels
Front Hub
Sealed Bearing, 15x100mm, 6-bolt
Rear Hub
Sealed Bearing, 12x142mm, HG, 6 Bolt
Rims
Alloy DW Disc, 27.5"
Tires
Front: Kenda Kwick Seven5, 2.2", 60 TPI, Gumwall, Rear: Kenda Kwick Seven5, 2.2", 60 TPI, Gumwall
Brakes
Brakes
Front: Tektro HD-M275, Hydraulic Disc, E-Rated, Resin Pads, Rear: Tektro HD-M275, Hydraulic Disc, E-Rated, Resin Pads
Brake Levers
Tektro HD-M285 Hydraulic
Cockpit
Stem
Alloy 70mm (S, M), 80mm (L), 31.8mm Clamp
Handlebar
Custom Alloy 660mm, 60mm Rise
Grips
Dual Density Ergonomic, Single Lock
Headset
Zero Stack
Seat
Saddle
Norco Comfort, Elastomers
Seatpost
JD TranzX Dropper, 31.6mm, 80mm (S, M), 100mm (L)
Motor & Battery
Motor
Shimano STEPS E6100
Battery
Shimano E8010 504Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.69 mm | 1.72 mm | 1.75 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm |
| Front Center | 625 mm | 646 mm | 667 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 88 mm | 88 mm | 88 mm |
| Stack | 584 mm | 612 mm | 640 mm |
| Reach | 346 mm | 356 mm | 366 mm |
| Top Tube Length | 586 mm | 607 mm | 628 mm |
| Seat Tube Angle | 68 ° | 68 ° | 68 ° |
| Seat Tube Length | 425 mm | 450 mm | 475 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 170 mm | 200 mm | 230 mm |
| Chainstay Length | 461 mm | 461 mm | 461 mm |
| Wheelbase | 1078 mm | 1099 mm | 1120 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm |
| Standover Height | 406 mm | 406 mm | 406 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 153 cm | 161 cm | 168 cm |
| Rider Max Height | 163 cm | 171 cm | 179 cm |
Model Overview
Scene VLT completes the Norco E Scene model. Norco launched 4 e-bikes of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid e-bikes average price
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco Scene VLT price was 2699$. Comparing this to the average Hybrid e-bike price, we see that the price is 8.83% more expensive.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Scene VLT components
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels size
The Scene VLT 2023 e-bike is equipped with aluminum wheels when leaving the factory. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Scene VLT has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Scene VLT comes in 3 sizes, that range from 153 cm – 179 cm (5.02 ft – 5.87 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Norco Scene VLT includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
