Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 80mm -
Fork SunTour XCT
-
Groupset Acera, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum with custom tube shapes, semi integrated headtube
Suspension Fork
SR Suntour XCT V2 80 mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera RD-M-310 7 speed
Front Derailleur
Shimano FD-C050 31.8
Shift Levers
Shimano ST-EF50 EZ-Fire, 7 speed front and rear
Cassette
Shimano MF-TZ-07, 7speed, 14-28T
Crank
Shimano FC-151, 42/34/24 T black alloy
Bottom Bracket
CH-52 EN cartridge BB
Chain
KMC Z-51
Pedals
MTB resin body / steel cage
Wheels
Front Hub
Formula alloy QR with disc mount
Rear Hub
Formula alloy QR, for 7 sp thread on FW, with disc mount
Rims
DDM-1 double wall alloy 32 hole
Spokes
Stainless steel 2.0
Tires
Innova MTB 26 x 1.95
Brakes
Brakes
Hayes MX-4 6” rotor
Brake Levers
Shimano EF-50 brake/ shifter
Cockpit
Stem
MTB alloy threadless 1-1/8 stem
Handlebar
MTB 30 mm rise bar , sand blast black
Grips
MTB design krayton rubber
Headset
CH 918 semi integrated threadless
Seat
Saddle
Norco MTB saddle, custom cover design
Seatpost
Kalloy micro adjust 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12.5" | 15" | 17" | 18.5" | 20" | 22" |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm | 300 mm | 300 mm | 300 mm |
| Front Center | 626 mm | 631 mm | 646 mm | 656 mm | 666 mm | 676 mm |
| Top Tube Length | 543 mm | 558 mm | 573 mm | 588 mm | 603 mm | 618 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 318 mm | 381 mm | 432 mm | 470 mm | 508 mm | 559 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 125 mm | 130 mm | 140 mm | 155 mm | 170 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1056 mm | 1061 mm | 1077 mm | 1087 mm | 1096 mm | 1106 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 718 mm | 736 mm | 766 mm | 785 mm | 807 mm | 836 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
About this model
SCRAMBLER is a Norco Scrambler model. There are 4 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2009 for 475$. Comparing this to the average Crosscountry bike price, we see that the price is 301.05% lower.
SCRAMBLER components
Fork
The fork installed on this bike is the SunTour XCT model. The travel on this model is 80mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The wheels on SCRAMBLER are the 26″ aluminum type. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco SCRAMBLER has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
