Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Lyrik Ultimate
-
Groupset GX Eagle Transmission, SRAM -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
1
154cm - 165cm
2
162cm - 172cm
3
170cm - 180cm
4
177cm - 188cm
5
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sight Aluminum, VPSHP, 150mm Travel, UDH Compatible
Suspension Fork
RockShox Lyrik Ultimate, Charger 3, 160mm, 44mm offset, Fender Included
Rear Shock
RockShox Super Deluxe Ultimate Coil, 205x60mm Trunnion, Sprindex Spring
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS T-Type
Shift Levers
SRAM Pod Ultimate Controller
Cassette
SRAM CS 1275 Eagle T-Type 10-52T
Crank
SRAM GX Eagle T-Type, 32T, 170mm
Bottom Bracket
SRAM DUB BSA Threaded
Chain
SRAM GX Eagle T-Type
Chain Guide
Norco Idler Guide and Lower Guide
Wheels
Front Hub
Race Face Vault, 15x110mm Boost, 6-Bolt
Rear Hub
Race Face Vault 12x148mm Boost, XD, 6-Bolt
Rims
Stan's Flow S2, Black 32H, 29"/27.5"
Tires
Front: Maxxis Minion DHF 2.5", 3C, MaxxTerra / EXO+ / TR, Folding, Rear: Maxxis Minion DHR II 2.4" WT, 3C, MaxxTerra / EXO+ / TR, Folding
Brakes
Brakes
Front: SRAM Code Bronze Stealth, Rear: SRAM Code Bronze Stealth, 4-Piston, Sintered Pads
Brake Levers
SRAM Code Bronze Stealth
Cockpit
Stem
CNC Alloy 40mm Length, 35mm Clamp
Handlebar
6061 Alloy, 800mm 25mm Rise
Grips
WTB Wavelength Lock-On
Headset
FSA #57 E Sealed Bearing
Seat
Saddle
SDG Bel Air V3
Seatpost
TranzX YS108 Dropper, 34.9mm, 150mm (1), 170mm (2), 200 (3, 4), 230mm (5)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.463 mm | 1.401 mm | 1.346 mm | 1.296 mm | 1.252 mm |
| Bottom Bracket Height | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 135 mm | 135 mm | 135 mm | 135 mm | 135 mm |
| Stack | 618 mm | 627 mm | 636 mm | 645 mm | 654 mm |
| Reach | 422.5 mm | 447.5 mm | 472.5 mm | 497.5 mm | 522.5 mm |
| Top Tube Length | 565 mm | 589 mm | 613 mm | 637 mm | 661 mm |
| Seat Tube Angle | 77 ° | 77.25 ° | 77.5 ° | 77.75 ° | 78 ° |
| Seat Tube Length | 350 mm | 370 mm | 385 mm | 430 mm | 445 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 420 mm | 424 mm | 428 mm | 432 mm | 436 mm |
| Wheelbase | 1181 mm | 1214 mm | 1247 mm | 1281 mm | 1314 mm |
| Standover Height | 666 mm | 680 mm | 689 mm | 710 mm | 720 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 162 cm | 170 cm | 177 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 180 cm | 188 cm | 195 cm |
