nordest 3003 CARBON Frameset 2024
2024 Road
Estimate price |
1,146$
Weight | 2.49 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Seatclamp 28.6mm, include with frame
Suspension Fork
Nordest Albarda Carbon fork with 400mm long and 47/52mm rake
Drivetrain
Crank
46T max chainring in 1x or 50T/34/ in 2x
Seat
Seatpost
For 27.2mm seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.586 mm | 1.536 mm | 1.495 mm | 1.458 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 620 mm | 645 mm | 671 mm | 696 mm |
| Rake | 52 mm | 52 mm | 52 mm | 52 mm |
| Trail | 78 mm | 78 mm | 78 mm | 78 mm |
| Stack | 582 mm | 596 mm | 610 mm | 624 mm |
| Reach | 367 mm | 388 mm | 408 mm | 428 mm |
| Top Tube Length | 529 mm | 553 mm | 577 mm | 607 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 530 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 140 mm | 155 mm | 170 mm | 185 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1025 mm | 1051 mm | 1077 mm | 1102 mm |
| Bottom Bracket Drop | 85 mm | 85 mm | 85 mm | 85 mm |
| Wheels | 700 | 700 | 700 | 700 |
