nordest SARDINHA 2 FRAME 2024
2024 Mountain
Estimate price |
836$
Weight | 2.75 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Steel
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Frame CRMO 4130 double butted
Seat
Seatpost
For 31.6mm seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | MD/LG | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.377 mm | 1.322 mm | 1.282 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm |
| Front Center | 722 mm | 751 mm | 782 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 95 mm | 95 mm |
| Stack | 599 mm | 608 mm | 622 mm |
| Reach | 435 mm | 460 mm | 485 mm |
| Top Tube Length | 600 mm | 627 mm | 661 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 420 mm | 450 mm | 485 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1145 mm | 1174 mm | 1205 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 27" | 27" | 27" |
