Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Tektro Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS Bikes AL6061-T6 custom formed and butted tubes
Suspension Fork
Suntour XCM 26’, 100mm travel, 9mm axle, soft spring, 1&1/8” steerer tube
Rear Shock
/
Drivetrain
Shift Levers
Shimano Altus 8spd
Cassette
Shimano CS-HG41 8spd 11-32t
Crank
Samox 152mm 32t Narrow Wide
Bottom Bracket
FSA BSA square taper
Chain
KMC, 8spd
Chain Guide
/
Pedals
NS Nylon
Wheels
Front Hub
Joytech 9mm bolt-on
Rear Hub
Joytech cassette 10mm bolt-on
Rims
ALEX XD-ELITE, 24”, 32h
Spokes
Spokes w/14mm nipples
Tires
Kenda Small Block 8 24x2.1
Brakes
Brakes
Tektro MD-M300 Aries 160mm
Cockpit
Stem
NS Drop JR 31.8, 50mm, angle –10°
Handlebar
NS Bar, 660mm 12mm rise
Grips
WTP Arrow 115, kids spec
Headset
FSA semi-integrated ZS44/ZS44, cartridge
Seat
Saddle
Octane One Junior
Seatpost
Kalloy 30.9mm
Fit data
Geometry
