Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Rear 160mm -
Fork RockShox ZEB -
Groupset Deore -
Suspension Full -
Motor Shimano 85Nm mid-drive -
Battery SHIMANO STEPS -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS Bikes E-fine AL w/ 160mm travel, AL6061-T6 + AL6066-T6, custom hydroformed tubes, Shimano ep8 drive unit, integrated Shimano battery hight-capacity
Suspension Fork
Rock Shox ZEB Charger R 29,E-MTB, 15x110mm Boost, 1.5 tapered steerer tube, 44mm offset
Rear Shock
Rock Shox Super Deluxe Coil Select, Trunnion 205x62,5
Drivetrain
Rear Derailleur
Shimano Deore RD-M6100, 12spd
Shift Levers
Shimano Deore SL-M6100, Rapidfire Plus, 12spd
Cassette
Shimano CS-MZ800, 11-51t 12spd
Crank
Shimano FC-EM600 160mm 36t
Chain
Shimano Deore CN-M6100, 12spd
Chain Guide
/
Wheels
Front Hub
NS Bikes Rotary 110x15mm Boost (sealed bearings)
Rear Hub
NS Rotary Cassette 148x12mm Boost (sealed bearings)
Rims
NS Enigma Rock 29” front, NS Enigma Rock 27,5” rear, 32h, tubeless ready
Spokes
Spokes w/14mm nipples
Tires
Maxxis Assegai MaxxGrip 3C DD TR 29x2.50 / Maxxis Assegai MaxxGrip 3C DD TR 27.5x2.50
Brakes
Brakes
Front: Shimano Deore M6120 4 piston, 203mm, Rear: Shimano Deore M6120 4 piston, 203mm
Cockpit
Stem
NS Quantum Lite 35, 45mm
Handlebar
NS Bar 35, 800mm, 20mm rise
Grips
NS Hold Fast
Headset
NS Bikes custom tapered IS42/IS52, sealed bearing
Seat
Saddle
WTB Volt Medium Cromoly
Seatpost
Race Face Aeffect R internal S
Motor & Battery
Motor
Shimano EP8
Battery
SHIMANO STEPS
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.496 mm | 1.429 mm | 1.365 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 335 mm |
| Front Center | 779 mm | 805 mm | 838 mm |
| Rake | 32 mm | 26 mm | 27 mm |
| Trail | 149 mm | 155 mm | 154 mm |
| Stack | 636 mm | 646 mm | 655 mm |
| Reach | 425 mm | 452 mm | 480 mm |
| Top Tube Length | 597 mm | 622 mm | 654 mm |
| Seat Tube Angle | 75.2 ° | 75.2 ° | 75.2 ° |
| Seat Tube Length | 396 mm | 432 mm | 480 mm |
| Head Tube Angle | 63.8 ° | 63.8 ° | 63.8 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1233 mm | 1259 mm | 1292 mm |
| Bottom Bracket Drop | -10 mm | -10 mm | -10 mm |
| Standover Height | 783 mm | 786 mm | 789 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
