Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Manitou Machete Comp
-
Groupset GX -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS BIKES AL6061-T6 CUSTOM 24 INCH (26 INCH COMPATIBLE) 135X10 VERTICAL DROPOUTS
Suspension Fork
MANITOU MACHETE COMP 26" 100MM TRAVEL, TAPERED, 15X100MM
Drivetrain
Shift Levers
SRAM GX 10S
Cassette
SRAM GX 10S 11-36
Crank
NS BIKES JUNIOR 140MM, NARROW-WIDE 30T CHAINRING
Bottom Bracket
BSA 73MM
Chain
SRAM PC1031, 10S
Pedals
VP-225 JUNIOR PLATFORM
Wheels
Front Hub
NS BIKES 15X100MM W/SEALED BEARINGS
Rear Hub
NS CASSETTE 135X10 W/SEALED BEARINGS
Tires
SCHWALBE ROCKET RON 24X2.35"
Brakes
Brakes
REVER ATTACK-U, 160MM ROTORS
Cockpit
Stem
NS DROP 31.8, 50MM, +10° ANGLE
Handlebar
NS BIKES 680MM WIDE, 31.8MM, 20MM RISE
Grips
SALT WTB ARROW 115
Headset
INTEGRATED TAPERED STEERER, IS42/52, SEALED BEARINGS
Seat
Saddle
SELLE ITALIA JUNIOR
Seatpost
KALLOY 31.6MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.453 mm |
| Bottom Bracket Height | 280 mm |
| Front Center | 629 mm |
| Rake | 18 mm |
| Stack | 545 mm |
| Reach | 375 mm |
| Top Tube Length | 526 mm |
| Seat Tube Angle | 74.5 ° |
| Seat Tube Length | 310 mm |
| Head Tube Angle | 65.5 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 394 mm |
| Wheelbase | 1021 mm |
| Bottom Bracket Drop | 33 mm |
| Standover Height | 620 mm |
| Front Travel | 100 mm |
| Wheels | 24" |
