Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Travel Front 140mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS Bikes 4130 cromoly frame, built with Tange Eccentric tubes, Boost 148x12 dropouts
Suspension Fork
Rock Shox Recon 140mm travel, 15x110mm Boost, 1.5 tapered steerer tube
Rear Shock
/
Drivetrain
Shift Levers
Shimano Deore M6100, 12spd
Cassette
Sunrace CSMZ800, 12spd 11-51T
Crank
Shimano Deore FCMT5101 170mm 32t
Bottom Bracket
Shimano BSA 73mm
Chain
Shimano, 12 spd
Chain Guide
/
Pedals
/
Wheels
Front Hub
NS Rotary 15 Boost 110x15 disc (sealed bearings)
Rear Hub
NS Rotary Cassette 148x12mm Boost (sealed bearings)
Rims
Octane One Solar 29”, 32h, tubeless compatible
Spokes
Spokes w/14mm nipples
Tires
Maxxis DHF EXO/TR 29x2.5" WT / Maxxis Aggressor EXO/TR 29x2.5" WT
Brakes
Brakes
Shimano MT410, 180mm
Cockpit
Stem
NS Tone 31.8, 45mm
Handlebar
NS Bar 31.8, 780mm 20mm rise
Grips
NS Hold Fast
Headset
GW integrated tapered IS42/IS52, sealed bearings
Seat
Saddle
Octane One Rocket2, CrMo hollow rails
Seatpost
X-Fusion Manic internal 125, 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.508 mm | 1.424 mm | 1.368 mm |
| Bottom Bracket Height | 434 mm | 434 mm | 434 mm |
| Front Center | 760 mm | 779 mm | 809 mm |
| Rake | 5 mm | 0 mm | 0 mm |
| Trail | 169 mm | 175 mm | 175 mm |
| Stack | 641 mm | 641 mm | 650 |
| Reach | 425 mm | 450 mm | 475 mm |
| Top Tube Length | 609 mm | 634 mm | 662 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 412 mm | 450 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1183 mm | 1203 mm | 1232 mm |
| Bottom Bracket Drop | -60 mm | -60 mm | -60 mm |
| Standover Height | 745 mm | 767 mm | 802 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
