Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork RST ALPHA
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS Bikes AL6061-T6 custom formed and butted tubes, 135x10 dropouts
Suspension Fork
RST Alpha 29 120mm travel, 110x15mm Boost, 1.5T
Rear Shock
/
Drivetrain
Shift Levers
Shimano Deore M5120, 10spd
Cassette
Sunrace CSMS2 10spd 11-42t
Crank
Sunrace FCM80T 30t 175mm
Bottom Bracket
FSA BSA square taper 73mm
Chain
KMC, 10spd
Chain Guide
/
Pedals
/
Wheels
Front Hub
NS Bikes 110x15mm Boost (loose ball)
Rear Hub
NS Bikes 135x9mm QR (loose ball)
Rims
Octane One Solar 29”, 32h, tubeless compatible
Spokes
Spokes w/14mm nipples
Tires
Schwalbe Nobby Nic 29x2.35"
Brakes
Brakes
Shimano hydraulic BL-MT200, 160mm
Cockpit
Stem
NS Drop 31.8, 50mm, angle –10°
Handlebar
NS Bar 31.8, 760mm 12mm rise
Grips
NS Hold Fast Unlocked
Headset
GW integrated tapered IS42/IS52, sealed bearings
Seat
Saddle
WTB Volt Medium Steel
Seatpost
Kalloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.489 mm | 1.444 mm | 1.385 mm |
| Bottom Bracket Height | 429 mm | 429 mm | 429 mm |
| Front Center | 718 mm | 743 mm | 771 mm |
| Rake | 7 mm | 8 mm | 7 mm |
| Trail | 155 mm | 154 mm | 155 mm |
| Stack | 618 mm | 628 mm | 637 mm |
| Reach | 415 mm | 435 mm | 460 mm |
| Top Tube Length | 587 mm | 610 mm | 637 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 407 mm | 445 mm | 495 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Chainstay Length | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1132 mm | 1157 mm | 1185 mm |
| Bottom Bracket Drop | -55 mm | -55 mm | -55 mm |
| Standover Height | 725 mm | 751 mm | 786 mm |
| Front Travel | 120 mm | 120 mm | 120 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
