Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Marzocchi Bomber Z2
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS Bikes AL6061-T6 custom formed and butted tubes, tapered integrated headtube 135x10mm dropouts
Suspension Fork
Marzocchi Bomber Z2 100mm travel, air spring, tapered steerer, 15x110mm boost axle
Rear Shock
/
Drivetrain
Rear Derailleur
Shimano Deore 10 speed shadow plus
Shift Levers
Shimano Deore 10 speed Rapidfire plus
Cassette
Shimano Deore 10 speed, 11-42t
Crank
NS Bikes Junior 152mm, narrow-wide 32t chainring
Bottom Bracket
BSA Square taper 73mm, sealed bearings
Chain
KMC X10-1
Chain Guide
/
Pedals
/
Wheels
Front Hub
NS Bikes 110x15mm
Rear Hub
NS Cassette 135x10mm
Rims
NS Bikes 27,5", 25mm wide
Spokes
Spokes w/14mm nipples
Tires
Schwalbe Nobby Nic 27.5x2.25"
Brakes
Brakes
Front: Shimano MT200, 160mm, Rear: Shimano MT200, 160mm
Cockpit
Stem
NS Drop 31.8, 50mm, angle –10°
Handlebar
NS 31.8, 720mm 12mm rise
Grips
WTP Arrow 115, kids spec
Headset
Integrated tapered steerer, IS42/52, sealed bearings
Seat
Saddle
Selle Italia Junior
Seatpost
Kind Shock Rage I internal 100mm 31,6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.478 mm |
| Bottom Bracket Height | 423 mm |
| Front Center | 682 mm |
| Rake | -14 mm |
| Trail | 174 mm |
| Stack | 591 mm |
| Reach | 400 mm |
| Top Tube Length | 558 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 355 mm |
| Head Tube Angle | 66 ° |
| Chainstay Length | 415 mm |
| Wheelbase | 1088 mm |
| Bottom Bracket Drop | -68 mm |
| Standover Height | 644 mm |
| Front Travel | 100 mm |
| Wheels | 27" |
