Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 130mm -
Travel Rear 120mm -
Fork Marzocchi Bomber Z2
-
Groupset SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes SRAM Level Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS Nerd Mini w/ 120mm travel, AL6061-T6, custom formed and butted tubes
Suspension Fork
Marzocchi Bomber Z2, 130mm travel, 110x15mm, 1.5T
Rear Shock
Manitou Radium Expert 190x40
Drivetrain
Shift Levers
SRAM SX Eagle™, 12spd
Cassette
SRAM PG-1210,12spd 11-50t
Crank
Truvativ SX Eagle™ PS 155mm 32t
Bottom Bracket
SRAM Power Spline BSA Bottom Bracket
Chain
SRAM, 12 spd
Chain Guide
/
Pedals
/
Wheels
Front Hub
NS 15 15x100 disc (sealed bearings)
Rear Hub
NS Cassette 148x12mm Boost (sealed bearings)
Rims
Octane One Solar Lite 27.5”, 32h, tubeless ready
Spokes
Spokes w/14mm nipples
Tires
Maxxis Ardent 27.5 x 2.25
Brakes
Brakes
SRAM Level, 180mm
Cockpit
Stem
NS Tone 31.8, 45mm
Handlebar
NS Bar 720mm, 20mm rise
Grips
NS Hold Fast supersoft
Headset
GW integrated tapered IS42/IS52, sealed bearings
Seat
Saddle
WTB Volt Medium Steel SL
Seatpost
Kind Shock Rage i internal 100mm 31,6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.463 mm |
| Bottom Bracket Height | 393 mm |
| Front Center | 699 mm |
| Rake | 17 mm |
| Trail | 132 mm |
| Stack | 600 mm |
| Reach | 410 mm |
| Top Tube Length | 565 mm |
| Seat Tube Angle | 75.5 ° |
| Seat Tube Length | 355 mm |
| Head Tube Angle | 67 ° |
| Chainstay Length | 427 mm |
| Wheelbase | 1125 mm |
| Bottom Bracket Drop | -38 mm |
| Standover Height | 668 mm |
| Wheels | 27" |
