Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS AL6061-T6 custom formed and butted tubes, tapered integrated headtube, 142x12mm dropouts
Suspension Fork
NS Gravel+ full carbon fork, 15mm dropouts, NS thru axle
Drivetrain
Rear Derailleur
SRAM Apex type 2.1, long cage, 11spd
Shift Levers
SRAM Apex 11spd
Cassette
Sun Race CSMS7 11-42t
Crank
Rondo S:170mm, M:172.5mm, L:175mm 42t
Bottom Bracket
Shimano PF 86,5
Chain
SRAM, 11 spd
Wheels
Front Hub
NS Bikes 100x15mm (sealed bearings)
Rear Hub
NS Bikes 142x12mm (sealed bearings)
Rims
Alex Draw 2.1P Asymmetrical, 32h, tubeless compatible
Spokes
butted 2.0-1.5-2.0 w/ 14mm nipples
Tires
Vittoria Mezcal III 700x45c
Brakes
Brakes
SRAM Apex hydraulic disc, 160mm rear & front
Cockpit
Stem
RAG+ Stem 31.8 S:80mm, M:90mm, L:100mm, XL:110mm, angle, - 8°
Handlebar
NS Flare 31.8, 420mm, 440mm, 460mm
Headset
GW integrated tapered IS42/52, sealed
Seat
Saddle
Selle Italia X3
Seatpost
Kalloy 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.388 mm | 1.47 mm | 1.48 mm | 1.512 mm |
| Bottom Bracket Height | 419 mm | 420 mm | 420 mm | 419 mm |
| Front Center | 609 mm | 615 mm | 636 mm | 656 mm |
| Rake | 2 mm | mm | mm | mm |
| Trail | 128 mm | 127 mm | 126 mm | 125 mm |
| Stack | 526 mm | 569 mm | 592 mm | 620 mm |
| Reach | 379 mm | 387 mm | 400 mm | 410 mm |
| Top Tube Length | 545 mm | 560 mm | 581 mm | 599 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 475 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 125 mm | 145 mm | 170 mm | 200 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1026 mm | 1033 mm | 1055 mm | 1075 mm |
| Bottom Bracket Drop | -70 mm | -71 mm | -71 mm | -70 mm |
| Standover Height | 756 mm | 785 mm | 818 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
