Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset X1, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes SRAM Level TLM Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS Synonym, superlite carbon fibre w/ 120mm travel
Suspension Fork
Fox Factory 34 Step Cast Float FIT4, 120mm travel, 2pos remote lockout w/ Open Mode Adj, push-to-unlock, 15x110mm Boost, 1.5 tapered steerer tube, 44mm offset
Rear Shock
Fox Factory Float DPS 2pos remote lockout, push-to-unlock, Evol LV Trunnion 165x42.5
Drivetrain
Shift Levers
SRAM GX Eagle, 12spd
Cassette
SRAM XG-1275, 10-50t 12 speed
Crank
SRAM X1 Carbon DUB 170mm 34t (XL size 175mm)
Bottom Bracket
SRAM DUB Press Fit BB92
Chain
SRAM GX Eagle, 12 spd
Chain Guide
/
Pedals
/
Wheels
Front Hub
NSBikesxHunt straight pull 110x15mm Boost (sealed bearings)
Rear Hub
NSBikesxHunt straight pull 148x12mm Boost (sealed bearings)
Rims
NS Bikes x Hunt 30 29", 32h, tubeless ready
Spokes
Straight Pull Spokes
Tires
Maxxis Recon 2.4WT EXO/TR / Maxxis Ikon 2.35 EXO/TR
Brakes
Brakes
SRAM Level TLM, 180mm
Cockpit
Stem
Synonym Trail 31.8 (S: 50, M, L & XL: 60mm), angle +5°
Handlebar
NS Licence Carbon Mini Rise Lite 31.8, 760mm, 15mm rise
Grips
NS Hold Fast supersoft
Headset
FSA NO.42/47/ACB
Seat
Saddle
WTB Volt Medium Cromoly
Seatpost
Fox Transfer Factory S: 120mm, M, L, XL: 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.353 mm | 1.285 mm | 1.251 mm | 1.237 mm |
| Bottom Bracket Height | 326 mm | 326 mm | 326 mm | 326 mm |
| Front Center | 732 mm | 766 mm | 796 mm | 824 mm |
| Rake | 14 mm | 14 mm | 13 mm | 13 mm |
| Trail | 151 mm | 151 mm | 153 mm | 153 mm |
| Stack | 590 mm | 599 mm | 614 mm | 632 mm |
| Reach | 436 mm | 466 mm | 491 mm | 511 mm |
| Top Tube Length | 582 mm | 615 mm | 644 mm | 667 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 410 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1167 mm | 1201 mm | 1232 mm | 1260 mm |
| Bottom Bracket Drop | -38 mm | -38 mm | -38 mm | -38 mm |
| Standover Height | 754 mm | 753 mm | 753 mm | 754 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
