oggi Cadenza 500 Disc 2025
2025 Road
Estimate price |
3,504$
Weight | 8.4 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Oggi 700 full carbon racing press fit 86 mm tapered rota de cabos interna
Suspension Fork
OGGI CARBON RACING
Drivetrain
Crank
PDV 105 FC-R7000 170mm 52 X 36T (para os tamanhos XS / S) PDV 105 FC-R7000 172.5mm 52 X 36T (para os tamanhos M / L) PDV 105 FC-R7000 175mm 52 X 36T (para os tamanhos XL)
Bottom Bracket
BB86/BB92, press-fit
Chain
SHIMANO 105 - CN HG 601 - 11 V
Wheels
Front Hub
par de rodas Shimano WH-RS171 dianteira trhu axle 100 x 12 mm, traseira trhu axle 142 x 12 mm para freio a disco
Rear Hub
par de rodas Shimano WH-RS171 dianteira trhu axle 100 x 12 mm, traseira trhu axle 142 x 12 mm para freio a disco
Rims
Par de rodas Shimano WH-RS171 dianteira trhu axle 100 x 12 mm traseira trhu axle 142x12mm para freio a disco
Spokes
par de rodas Shimano WH-RS171 dianteira trhu axle 100 x 12 mm, traseira trhu axle 142 x 12 mm para freio a disco
Tires
Kenda 700 x 28C - Valkyrie 1160A TLR 120 TPI
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
ITM ALCOR 80 31.8 mm over 440 mm com 125mm drop e 70 mm short-reach (para o tamanho XL) / ITM ALCOR 80 31.8 mm over 420 mm com 125mm drop e 70 mm short-reach (para o tamanho L) / ITM ALCOR 80 31.8 mm over 400 mm com 125mm drop e 70 mm short-reach ( para o tamanho XS / S / M )
Headset
JG MOV DIREÇÃO FSA 42 ACB
Seat
Saddle
Velo
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.451 mm | 1.466 mm | 1.488 mm | 1.519 mm |
| Stack | 535 mm | 547 mm | 560 mm | 576 mm | 594 mm |
| Reach | 374 mm | 377 mm | 382 mm | 387 mm | 391 mm |
| Top Tube Length | 521 mm | 531 mm | 545 mm | 560 mm | 573 mm |
| Seat Tube Angle | 74.5 ° | 74.2 ° | 73.7 ° | 73.3 ° | 73 ° |
| Seat Tube Length | 450 mm | 475 mm | 500 mm | 525 mm | 550 mm |
| Head Tube Angle | 72 ° | 73 ° | 73 ° | 73.5 ° | 73.8 ° |
| Head Tube Length | 130 mm | 140 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 974 mm | 975 mm | 982 mm | 988 mm | 995 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
