Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Travel Rear 120mm -
Fork Manitou Machete Comp
-
Groupset Race Face -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NOVO QUADRO MTB FULL SUSPENSION em fibra de carbono para 120mm de curso, BSA 73mm, rear e-thru axle 148x12mm, head tube tapered c/passagem interna para canote retrátil
Suspension Fork
MANITOU MACHETE COMP 29 com eixo de 110x15mm + (trava no guidão) – curso de 120mm
Drivetrain
Crank
RACE FACE/SHIMANO DEORE FC-MT5101 (34D 175mm com eixo integrado - BOOSTER)
Bottom Bracket
BSA, 73mm, threaded
Chain
SHIMANO DEORE CN-M6100
Wheels
Front Hub
SHIMANO MT410 p/110 x 15mm 32 furos p/freio a disco
Rear Hub
SHIMANO MT410 p/12 x 148 mm true axle type c/eixo de 12 mm 32 fros p/freio a disco
Rims
Cubo Shimano Deore com aros Alexrims MD 25
Spokes
Aço inoxidável
Tires
Kenda Booster PRO 29x2.20
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
RACE FACE RIDE 35X760mm
Headset
NECO tapered selado
Seat
Saddle
MTB VELO
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.463 mm | 1.384 mm | 1.316 mm | 1.288 mm |
| Stack | 607 mm | 616 mm | 625 mm | 644 mm |
| Reach | 415 mm | 445 mm | 475 mm | 500 mm |
| Top Tube Length | 572 mm | 607 mm | 639 mm | 685 mm |
| Seat Tube Angle | 75.32 ° | 75.32 ° | 75.32 ° | 75.32 ° |
| Seat Tube Length | 400 mm | 440 mm | 460 mm | 500 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
