Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork Manitou Markhor
-
Groupset Race Face -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NOVO quadro de carbono super light, com seat stay mais baixo e compatível com sistema SRAM T-TYPE e shimano com UDH, rear e-thru axle 12x148mm, press fit com rota interna dos cabos c/sistema simple routing system (SRS)
Suspension Fork
Manitou Markhor 29 com eixo de 110 x 15mm (trava no guidão) – curso de 100mm
Drivetrain
Crank
Shimano DEORE/RACE FACE - 34D 175mm com eixo integrado
Bottom Bracket
BB86/BB92, press-fit
Chain
Shimano DEORE CN-M6100
Wheels
Front Hub
SHIMANO MT410 p/110 x 15 mm 32 furos p/freio a disco
Rear Hub
SHIMANO MT410 p/12 x 148mm true axle type c/eixo de 12 mm 32 furos p/freio a disco
Rims
Cubos Shimano Deore com aros Alexrims MD25
Spokes
Aço inoxidável
Tires
Kenda Booster PRO 29x2.20
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
MTB ITM NH1 flat 31.8mm over c/700 mm em alumínio preto
Headset
TAPERED
Seat
Saddle
MTB VELO
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.343 mm | 1.281 mm | 1.27 mm |
| Stack | 598 mm | 603 mm | 607 mm | 617 mm |
| Reach | 421 mm | 449 mm | 474 mm | 486 mm |
| Top Tube Length | 575 mm | 604 mm | 630 mm | 645 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 375 mm | 425 mm | 460 mm | 510 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 95 mm | 100 mm | 110 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
