Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Shimano -
Suspension Hardtail -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Quadro em alumínio 6061 T6 tratado c/tubo do selim com 34.9 mm c/ponteira post mount p/freio a disco e removível c/rota interna e rabeira snake e head tube over size (44/50)
Suspension Fork
SUNTOUR XCM 29 com trava no guidão – curso de 100 mm
Drivetrain
Crank
Shimano CUES FC-U6000 32D 175mm com eixo integrado
Chain
Shimano CN-LG500
Wheels
Front Hub
Shimano c/quick release 32 furos p/freio a disco
Rear Hub
Shimano c/quick release 32 furos p/freio a disco
Rims
Shimano c/quick release com Aros Alexrims MD25
Spokes
Aço inoxidável
Tires
MTB 29 " x 2,10
Brakes
Brakes
Mechanical Disc
Cockpit
Handlebar
MTB reto 31,8 mm over em alumínio preto
Headset
Oversize ahead 44/50 semi-integrado e reforçado
Seat
Saddle
MTB – DDK
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.627 mm | 1.551 mm | 1.465 mm | 1.377 mm |
| Stack | 636 mm | 636 mm | 636 mm | 636 mm |
| Reach | 391 mm | 410 mm | 434 mm | 462 mm |
| Top Tube Length | 572 mm | 592 mm | 617 mm | 646 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm | 115 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1075 mm | 1096 mm | 1120 mm | 1148 mm |
| Wheels | 29" | 29" | 29" | 29" |
