Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NOVO OGGI Cadenza full carbon lower seat stay (lss) extra light carbon fiber, Shimano press fit 86mm internal cable rounting via ht, front derraileur brazed on type, flat mount to disc brake e-thru drop out 142x12mm
Suspension Fork
NOVO OGGI carbon racing taper, carbon steerer, carbon crown - thru axle 100x12mm
Drivetrain
Crank
Shimano 105 modelo FC-R7100 12V 50x34 dentes
Bottom Bracket
BB86/BB92, press-fit
Chain
Shimano 105 - CN M7100 12v
Wheels
Front Hub
Par de rodas FULCRUM RACING 800 - Dianteira thru axle 100 x 12 mm / Traseira thru axle 142 x 12 mm
Rear Hub
Par de rodas FULCRUM RACING 800 - Dianteira thru axle 100 x 12 mm / Traseira thru axle 142 x 12 mm
Rims
Par de rodas FULCRUM RACING 800 - Dianteira thru axle 100 x 12 mm / Traseira thru axle 142 x 12 mm
Spokes
Par de rodas FULCRUM RACING 800 - Dianteira thru axle 100 x 12 mm / Traseira thru axle 142 x 12 mm
Tires
700 x 28C
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
ITM (semi integrated cable routing)
Headset
Semi integrado
Seat
Saddle
Velo
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.397 mm | 1.395 mm | 1.397 mm | 1.403 mm | 1.45 mm |
| Stack | 512 mm | 528 mm | 538.1 mm | 560 mm | 588.5 mm |
| Reach | 366.4 mm | 378.6 mm | 385.3 mm | 399.1 mm | 406 mm |
| Top Tube Length | 513.2 mm | 530 mm | 544.7 mm | 565 mm | 580.4 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 565 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 96.5 mm | 113.7 mm | 126 mm | 140 mm | 154 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 970 mm | 983 mm | 984 mm | 999 mm | 1015 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
