Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Travel Rear 120mm -
Fork Manitou Machete Comp
-
Groupset Deore -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Quadro de carbono super light carbon, BSA 73 mm, rear e-thru axle 12 x 148 mm compatível com sistema SRAM T-TYPE e Shimano com UDH, rota interna dos cabos sistema SRS, 120mm de curso
Suspension Fork
MANITOU MACHETE COMP 29 com eixo de 110x15mm + (trava no guidão) – curso de 120mm
Drivetrain
Crank
Shimano Deore MT5101, 34 dentes 170 mm (S), 175 mm-(M/L/XL)
Bottom Bracket
BSA, 73mm, threaded
Chain
SHIMANO DEORE CN-M6100
Wheels
Front Hub
Shimano MT410/TC500 110x15 mm - 32 furos center lock
Rear Hub
Shimano MT410/TC500 148 x 12 mm - 32 furos (MS) micro spline center lock
Rims
Cubo Shimano Deore com aros Alexrims MD 25
Spokes
Aço inoxidável
Tires
29" X 2,25 - MAXXIS REKON RACE
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
RACE FACE RIDE 35X760mm
Headset
NECO tapered selado
Seat
Saddle
MTB VELO
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.463 mm | 1.384 mm | 1.316 mm | 1.288 mm |
| Stack | 607 mm | 616 mm | 625 mm | 644 mm |
| Reach | 415 mm | 445 mm | 475 mm | 500 mm |
| Top Tube Length | 572 mm | 607 mm | 639 mm | 685 mm |
| Seat Tube Angle | 75.32 ° | 75.32 ° | 75.32 ° | 75.32 ° |
| Seat Tube Length | 400 mm | 440 mm | 460 mm | 500 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
