onone On-One Wrekker SRAM GX AXS Titanium 2024
2024 Mountain
Estimate price |
4,462$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Titanium -
Travel Front 150mm -
Fork RockShox Pike Select
-
Groupset GX Eagle AXS -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 170cm
MD
168cm - 178cm
LG
175cm - 188cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
RockShox Pike Select 29" BOOST Fork / 150mm / 15 X 110mm / Gloss Black / Crown Adjust
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS Rear Derailleur / Lunar / With Battery Protector
Cassette
SRAM XG-1275 Eagle 12 Speed Cassette / 10-52T
Crank
SRAM GX Eagle DUB Crankset (Lunar Colourway) / 170mm / 32T / BOOST
Bottom Bracket
SRAM DUB BSA Bottom Bracket / 73mm
Chain
SRAM Chain PC NX Eagle / 126 Links / 12 Speed
Wheels
Rims
WTB I30 29er On Selcof 150 Boost 6 Bolt Wheelset / SRAM XD
Tires
Hutchinson Griffus 29" Tubeless Ready Tyre / 2.4" / Black
Brakes
Brakes
SRAM Guide G2 R Hydraulic Disc Brake / Rear / 1800 / 20 Post to IS
Cockpit
Stem
Selcof Tickety Boo Stem / 35mm
Handlebar
Selcof Enduro6 Riser Handlebar / 780mm
Seat
Saddle
San Marco GND Full-fit Start Up Wide Saddle
Seatpost
Rockshox Reverb Stealth Dropper Seatpost / 31.6mm / 2000mm Left / 467mm / 175mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.386 mm | 1.322 mm | 1.275 mm | 1.245 mm |
| Bottom Bracket Height | 324 mm | 324 mm | 324 mm | 324 mm |
| Front Center | 808 mm | 841 mm | 882 mm | 906 mm |
| Rake | 44 mm | 45 mm | 45 mm | 44 mm |
| Trail | 149 mm | 148 mm | 148 mm | 149 mm |
| Stack | 625 mm | 633 mm | 650 | 660 mm |
| Reach | 451 mm | 479 mm | 510 mm | 530 mm |
| Top Tube Length | 595 mm | 625 mm | 660 mm | 682 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 400 mm | 430 mm | 460 mm | 480 mm |
| Head Tube Angle | 62 ° | 62 ° | 62 ° | 62 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 150 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1262 mm | 1295 mm | 1335 mm | 1360 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 168 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 178 cm | 188 cm | 193 cm |
