Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour XCT
-
Groupset X3 -
Suspension Hardtail -
Brakes JAK Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Improved 6061 aluminum frame with shorter chainstays and more tire clearance
Suspension Fork
Suntour XCT JR 63 mm
Drivetrain
Rear Derailleur
SRAM X3
Front Derailleur
N/A
Shift Levers
SRAM 3.0 Twist 7
Cassette
Shimano Tourney 14-34
Crank
Samox alloy 127 mm
Bottom Bracket
5 pc steel
Chain
KMC Z51
Pedals
Wellgo resin
Wheels
Front Hub
Joytech
Rear Hub
Joytech
Rims
Ace disc double wall
Tires
Innova IA-2021 20 x 2.35
Brakes
Brakes
Jak-7 mechanical disc brakes - 160 mm
Brake Levers
Jak-7 mechanical disc brake Levers
Cockpit
Stem
Promax 60 mm 15°
Handlebar
Opus Junior 25.4
Headset
VP semi-integrated sealed
Seat
Saddle
Opus Junior
Seatpost
Opus Junior 27.2 x 300
Fit data
Geometry
