Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset Tourney, Altus -
Suspension Rigid -
Brakes Promax Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Vintage steel frame design
Suspension Fork
Opus Urban steel
Drivetrain
Rear Derailleur
Shimano Tourney TX 800
Front Derailleur
N/A
Shift Levers
Shimano Altus M310
Cassette
Shimano TZ-31 14-34t
Crank
CW alloy single ring
Bottom Bracket
CH-46-E cartridge
Chain
KMC-Z51
Pedals
FPD NW-99K
Wheels
Front Hub
Joytech alloy
Rear Hub
Joytech alloy
Rims
Ace DWS-002
Tires
Vittoria Randonneur 700 x 40c
Brakes
Brakes
Promax dual-pivot calipers
Brake Levers
Promax 3-finger alloy
Cockpit
Stem
Opus Gold-70/80/90 mm
Handlebar
Opus Lifestyle 40 mm rise
Headset
TH threadless
Seat
Saddle
Opus Lifestyle, microfiber
Seatpost
Opus Bronze 26.8 x 300
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.447 mm | 1.457 mm | 1.46 mm |
| Stack | 557 mm | 571 mm | 590 mm |
| Reach | 385 mm | 392 mm | 404 mm |
| Top Tube Length | 547 mm | 563 mm | 585 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 150 mm | 165 mm | 185 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 749 mm | 775 mm | 803 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
