Opus MONDANO ST 2025
2025 Urban
Estimate price |
434$
Weight | 13.43 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Meta 10 Alloy
Suspension Fork
Steel 1 1/8 in
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Tourney
Shift Levers
Shimano ST-EF500 3 x 7
Cassette
Shimano 12-28t
Crank
Suntour CW14-XCC-T102
Bottom Bracket
Neco cartridge
Chain
KMC-Z7
Pedals
FPD NW-420
Wheels
Front Hub
Joytech
Rear Hub
Joytech
Rims
Ace DW002
Tires
Kenda K935 700c x 45
Brakes
Brakes
ALHONGA HJ-811AD7
Brake Levers
Shimano
Cockpit
Stem
Promax adjustable quill
Handlebar
HL Alloy 40 mm rise
Headset
FP threaded
Seat
Saddle
Opus Comfort Plus
Seatpost
Promax Alloy 27.2 x 300
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.543 mm | 1.543 mm | 1.548 mm |
| Stack | 574 mm | 591 mm | 610 mm |
| Reach | 372 mm | 383 mm | 394 mm |
| Top Tube Length | 559 mm | 581 mm | 598 mm |
| Seat Tube Angle | 72 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 390 mm | 440 mm | 490 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 585 mm | 615 mm | 654 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
