Opus QUARTIER 8 2024
2024 Urban
Estimate price |
724$
Weight | 13.15 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney, Acera -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Meta 20 Alloy
Suspension Fork
Meta 10 Aluminum
Drivetrain
Rear Derailleur
Shimano Acera M3020
Shift Levers
Shimano Altus M315 2x8
Cassette
Shimano HG31 11-34
Crank
Shimano FC-TY501
Bottom Bracket
BB-73 BSA
Chain
KMC Z8.3
Pedals
FPD NW-99K
Wheels
Front Hub
Joytech disc
Rear Hub
Joytech disc
Rims
Weinmann U28 650b
Tires
Kenka Kwick Seven.5 650bx50c
Brakes
Brakes
Shimano BR-U300 flat-mount hydraulic disc
Brake Levers
Shimano BL-M200
Cockpit
Stem
Opus Gold
Handlebar
MJ HB-T321
Headset
FSA 42/48/ACB
Seat
Saddle
Opus Lifestyle Wide
Seatpost
Opus Bronze 27.2 x 350, 400(L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.667 mm | 1.675 mm | 1.669 mm |
| Stack | 585 mm | 613 mm | 636 mm |
| Reach | 351 mm | 366 mm | 381 mm |
| Top Tube Length | 599 mm | 626 mm | 651 mm |
| Seat Tube Angle | 67 ° | 67 ° | 67 ° |
| Seat Tube Length | 380 mm | 450 mm | 500 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 160 mm | 190 mm | 215 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
