Opus RAILTRAIL 2025
2025 E-bike
Estimate price |
2,462$
Weight | 21 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lightweight trail inspired aluminum frame
Suspension Fork
Suntour XCM-34 100mm NLO boost with lockout
Drivetrain
Rear Derailleur
Shimano Deore 5100
Front Derailleur
N/A
Shift Levers
Shimano Deore 11
Cassette
Shimano 11-42
Crank
Shimano FC-E6100
Bottom Bracket
N/A
Chain
KMC E11S
Pedals
FPD NW-420
Wheels
Front Hub
Shimano
Rear Hub
Shimano
Rims
Weinnman U32 TL
Tires
Kenda Booster 29 x 2.2
Brakes
Brakes
Shimano BR-MT420 hydraulic disc
Brake Levers
Shimano BL-MT401
Cockpit
Stem
Zoom Tequila 45/55mm
Handlebar
Zoom Tequila 780mm 35.0°
Headset
FSA Orbit integrated sealed
Seat
Saddle
Opus Endurance
Seatpost
Promax 31.6 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.637 mm | 1.633 mm | 1.561 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm |
| Stack | 627 mm | 645 mm | 657 mm |
| Reach | 383 mm | 395 mm | 421 mm |
| Top Tube Length | 557 mm | 585 mm | 616 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 480 mm | 510 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
