Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour XCT
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Improved 6061 aluminum frame with better tire clearance and shorter chainstays
Suspension Fork
Suntour XCT JR DS 80 mm
Drivetrain
Rear Derailleur
Shimano Altus 7 Spd
Shift Levers
Shimano Altus 3 x 7
Cassette
Shimano HG20 12-32
Crank
Lasco alloy 152 mm
Bottom Bracket
5 pc steel
Chain
KMC Z51
Pedals
Wellgo resin
Wheels
Front Hub
Joytech
Rear Hub
Joytech
Rims
Ace Disc double wall
Tires
Innova IA-2024 24 x 2.35
Brakes
Brakes
Jak-7 mechanical disc brakes - 160 mm
Brake Levers
Jak-7 mechanical disc
Cockpit
Stem
XFX 60mm 15°
Handlebar
Opus Junior 25.4
Headset
VP sealed semi-integrated
Seat
Saddle
Opus Youth Sport Trail
Seatpost
Opus Junior 27.2 x 300
Fit data
Geometry
