Opus RECRUIT 2 2024
2024 Mountain
Estimate price |
941$
Weight | 14.38 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Meta 20 Alloy
Suspension Fork
Suntour XCM-32 120 mm LO DS boost with lockout
Drivetrain
Rear Derailleur
Shimano Deore 5100
Shift Levers
Shimano Deore 1 x 11
Cassette
Shimano Deore 11-42
Crank
Shimano Deore 5100
Bottom Bracket
Shimano SM-BB52
Chain
KMC X11
Pedals
FPD NW-420
Wheels
Front Hub
Formula boost
Rear Hub
Formula boost
Rims
Weinnman U32 TL
Tires
Kenda Saber 29 x 2.2
Brakes
Brakes
Shimano BR-MT201 hydraulic disc
Brake Levers
Shimano BL-MT201
Cockpit
Stem
Opus Silver 6°
Handlebar
Opus Silver 15 mm rise 31.8
Headset
NECO semi-integrated
Seat
Saddle
Opus Endurance
Seatpost
Opus Silver 31.6 x 350
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 324 mm | 324 mm | 319 mm | 319 mm | 319 mm |
| Reach | 380 mm | 380 mm | 420 mm | 440 mm | 450 mm |
| Top Tube Length | 551 mm | 575 mm | 597 mm | 635 mm | 647 mm |
| Seat Tube Angle | 74 ° | 74.5 ° | 74.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 400 mm | 430 mm | 460 mm | 490 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 110 mm | 120 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
