Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Alivio, Altus -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Meta 30 Alloy
Suspension Fork
Aluminum tapered 1-1/2 to 1-1/8 in
Drivetrain
Rear Derailleur
Shimano Alivio shadow
Shift Levers
Shimano Altus 9
Cassette
Shimano 11-32
Crank
Shimano FC-E6100
Bottom Bracket
N/A
Chain
KMC E9S
Pedals
Wellgo flat
Wheels
Front Hub
Formula/Shimano
Rear Hub
Formula/Shimano
Rims
Weinnman U28 TL
Tires
Kenda Kwick Journey 700 x 42
Brakes
Brakes
Shimano BR-MT200 hydraulic disc
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Promax 70/80mm
Handlebar
Promax flat
Headset
FSA Orbit integrated sealed
Seat
Saddle
Opus E-CITY
Seatpost
Promax 30.9 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.558 mm | 1.501 mm | 1.48 mm |
| Stack | 623 mm | 623 mm | 632 mm |
| Reach | 400 mm | 415 mm | 427 mm |
| Top Tube Length | 590 mm | 605 mm | 620 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 145 mm | 145 mm | 155 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 740 mm | 780 mm | 810 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
