Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Shimano GRX 400 Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Gravel capable aluminum frame
Suspension Fork
Full carbon tapered 1-1/2 to 1-1/8 in
Drivetrain
Rear Derailleur
Shimano FD-RX820
Front Derailleur
Shimano RD-RX820
Shift Levers
Shimano ST-RX610 2x12
Cassette
Shimano 11-34
Crank
Shimano FC-RX610
Bottom Bracket
Shimano sealed BSA
Chain
Shimano M6100 HG 12s
Pedals
N/A
Wheels
Front Hub
FSA 12 x 100 mm / 12 x 142mm
Rear Hub
FSA 12 x 100 mm / 12 x 142mm
Rims
FSA Team 30 i23
Tires
Vittoria Terreno T50 Mixed Gravel Endurance 700x40c
Brakes
Brakes
Shimano RX 400 flat mount hydraulic
Cockpit
Stem
FSA Gossamer +/-6°
Handlebar
FSA NS Adventure compact 12° flare
Headset
FSA integrated sealed
Seat
Saddle
Opus Gravel
Seatpost
FSA Gossamer 27.2 x 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.435 mm | 1.473 mm | 1.508 mm | 1.542 mm | 1.563 mm | 1.578 mm |
| Stack | 534 mm | 554 mm | 573 mm | 592 mm | 611 mm | 631 mm |
| Reach | 372 mm | 376 mm | 380 mm | 384 mm | 391 mm | 400 mm |
| Top Tube Length | 515 mm | 530 mm | 544 mm | 559 mm | 578 mm | 599 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 510 mm | 545 mm | 580 mm |
| Head Tube Angle | 69.75 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 175 mm | 195 mm | 215 mm |
| Chainstay Length | 428 mm | 428 mm | 430 mm | 430 mm | 432 mm | 432 mm |
| Bottom Bracket Drop | 80 mm | 78 mm | 76 mm | 74 mm | 73 mm | 72 mm |
| Standover Height | 684 mm | 709 mm | 735 mm | 760 mm | 789 mm | 815 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
