Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Travel Front 40mm -
Fork Fox Performance Elite 32 TC
-
Groupset Apex, FSA -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Custom Butted OS Aluminium Tube. Wheel Size: 700c.
Suspension Fork
Fox 32 TC Performance Elite 40mm
Drivetrain
Rear Derailleur
SRAM Apex
Shift Levers
SRAM Apex
Cassette
Sunrace CSMS8 11-42t 11spd
Crank
FSA Omega 40t
Bottom Bracket
FSA Mega Exo
Chain
KMC 11spd
Wheels
Rims
DT Swiss G1800 700c
Tires
Goodyear Connector 700x40 Tan
Brakes
Brakes
SRAM Apex Hydraulic
Cockpit
Stem
Strange Stalk Gravel
Handlebar
Strange F-Bomb
Grips
Strange EAV Gel Bar Tape Black
Headset
FPD 44mm / 56mm zerostack
Seat
Saddle
WTB Volt Steel
Seatpost
KS Ragei 100mm Drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.492 mm | 1.481 mm | 1.491 mm | 1.501 mm |
| Front Center | 607 mm | 628 mm | 646 mm | 663 mm |
| Rake | -3 mm | -4 mm | -3 mm | -3 mm |
| Trail | 147 mm | 148 mm | 147 mm | 147 mm |
| Stack | 552 mm | 570 mm | 589 mm | 608 mm |
| Reach | 370 mm | 385 mm | 395 mm | 405 mm |
| Top Tube Length | 528 mm | 548 mm | 564 mm | 580 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1032 mm | 1053 mm | 1071 mm | 1088 mm |
| Bottom Bracket Drop | -65 mm | -65 mm | -65 mm | -65 mm |
| Standover Height | 736 mm | 752 mm | 770 mm | 795 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
X9 Pro completes the Orange X9 model. 1 bike variation carries this model name so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4447$. In conclusion, this bike price is 133.44% higher than the price of the average Crosscountry bike.
Overview of components
Fork
Orange X9 Pro 2023 bike is equipped with the Fox Performance Elite 32 TC fork, and has 40mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the X9 Pro model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The X9 Pro has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the X9 Pro. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
