Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
178cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Alma Carbon OMR, Boost 12x148, PF BB, Internal cable routing.
Suspension Fork
Fox 34 Float SC Performance 100 3POS Remote Push-Unlock QR15x110
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS Shadow Plus
Shift Levers
Shimano XT M8100 I-Spec EV
Cassette
Shimano CS-M7100 10-51t 12-Speed
Crank
Shimano XT M8100 34t
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano M7100
Wheels
Rims
Oquo Mountain Performance MP28PRO, alloy hookless rim, DT350 CL hub, Shimano Micro Spline freehub, 28mm internal width, Sapim Race spokes, 29"
Tires
Maxxis Rekon Race 2.35" 120 TPI Exo TLR
Brakes
Brakes
Shimano M6100 Hydraulic Disc
Cockpit
Stem
OC Mountain Performance MP20, -8º
Handlebar
OC Mountain Performance MP30, Width 760
Headset
Acros 1-1/8 - 1-1/2" Semi-intergated Block Lock
Seat
Saddle
Fizik Taiga S-alloy rail
Seatpost
Alloy, forged head, 27.2mm, Setback 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.501 mm | 1.413 mm | 1.366 mm | 1.319 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 660 mm | 695 mm | 721 mm | 752 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 593 mm | 602 mm | 612 mm | 625 mm |
| Reach | 395 mm | 426 mm | 448 mm | 474 mm |
| Top Tube Length | 559 mm | 593 mm | 618 mm | 647 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1083 mm | 1118 mm | 1144 mm | 1175 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 693 mm | 729 mm | 767 mm | 819 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 178 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
