Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 110mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Alma Carbon, Boost 12x148, Internal cable routing.
Suspension Fork
Fox 34 Float SC Performance 110 Grip Remote Push to Lock QR15x110
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS Shadow Plus
Shift Levers
Shimano XT M8100 I-Spec EV
Cassette
Shimano CS-M7100 10-51t 12-Speed
Crank
Shimano XT M8120 34t
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano M7100
Wheels
Rims
Oquo Mountain Performance MP28PRO
Tires
Pirelli Scorpion Sport XC H 2.40" 60TPI ProWall/TLR
Brakes
Brakes
Shimano M6100 Hydraulic Disc
Cockpit
Stem
OC Mountain Performance MP21, -6º
Handlebar
OC Mountain Performance MP30, Width 760
Grips
OC Lock On
Seat
Saddle
Prologo Akero RS steel rails
Seatpost
OC Mountain Performance DP-MP10, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.527 mm | 1.422 mm | 1.355 mm | 1.304 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 696 mm | 726 mm | 753 mm | 773 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 106 mm | 106 mm | 106 mm | 114 mm |
| Stack | 618.5 mm | 618.5 mm | 623.1 mm | 632.3 mm |
| Reach | 405 mm | 435 mm | 460 mm | 485 mm |
| Top Tube Length | 564 mm | 594 mm | 620 mm | 648 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 390 mm | 410 mm | 455 mm | 495 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1113 mm | 1143 mm | 1170 mm | 1190 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 794 mm | 797 mm | 811 mm | 829 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
