Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 20" -
Groupset Nexus, FSA -
Suspension Rigid -
Motor Bosch 250W 40Nm mid-drive -
Battery BOSCH Performance 400Wh -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Katu 20"
Suspension Fork
Orbea Katu
Drivetrain
Shift Levers
Shimano SL-C6000 Nexus 8-Speed
Cassette
Shimano Nexus 18t
Crank
FSA Bosch-IG3 E-bike 44t
Bottom Bracket
Bosch, press-fit
Chain
KMC Z510HX
Chain Guide
FSA Bosch IG3 44-46t
Pedals
VP-537 Black
Wheels
Rims
Orbea Web Disc
Tires
Kenda 841 20x2.25 Reflex
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Orbea Alu
Handlebar
Orbea City Riser Alu 660mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Selle Royal Milo Plus DR
Seatpost
Alloy 31.6x400mm Offset 0
Motor & Battery
Motor
BOSCH Active 25 kmh
Battery
BOSCH Performance 400Wh
Remote
BOSCH Performance Purion
Charger
Compact Charger 2A (100-240V) Worldwide
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | U |
|---|---|
| Stack Reach Ratio | 1.324 mm |
| Bottom Bracket Height | 268 mm |
| Front Center | 657 mm |
| Rake | 28 mm |
| Stack | 531 mm |
| Reach | 401 mm |
| Top Tube Length | 575 mm |
| Seat Tube Angle | 70.3 ° |
| Seat Tube Length | 468 mm |
| Head Tube Angle | 67.7 ° |
| Head Tube Length | 250 mm |
| Chainstay Length | 440 mm |
| Wheelbase | 1096 mm |
| Bottom Bracket Drop | 18 mm |
| Standover Height | 655 mm |
| Wheels | 20" |
| Rider Min Height | 120 cm |
About this model
KATU-E 30 completes the Orbea E Katu E model. 3 e-bikes variations carry this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Utility e-bikes
According to our calculations, the average cost of an Utility e-bike that is reliable is 3636$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Utility e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2022 for 2653$. In conclusion, this e-bike price is 37.05% smaller than the price of the average Utility e-bike.
Overview of components
Wheels
The KATU-E 30 2022 e-bike is equipped with 20″ aluminum wheels when leaving the factory. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea KATU-E 30 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
