Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 20" -
Groupset Nexus, FSA -
Suspension Rigid -
Motor Bosch 250W 40Nm mid-drive -
Battery BOSCH Performance 400Wh -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Katu 20"
Suspension Fork
Orbea Katu
Drivetrain
Shift Levers
Shimano SL-C6000 Nexus 8-Speed
Cassette
Shimano Nexus 18t
Crank
FSA Bosch-IG3 E-bike 44t
Bottom Bracket
Bosch, press-fit
Chain
KMC Z510HX
Chain Guide
FSA Bosch IG3 44-46t
Pedals
VP-537 Black
Wheels
Rims
Alloy, 20", 36H
Tires
Kenda 841 20x2.25 Reflex
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Orbea Alu
Handlebar
Orbea City Riser Alu 660mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Selle Royal Milo Plus DR
Seatpost
Alloy, 31.6mm, Setback 0
Motor & Battery
Motor
BOSCH Active
Battery
BOSCH Performance 400Wh
Charger
Compact Charger 2A (100-240V) Worldwide
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | U |
|---|---|
| Stack Reach Ratio | 1.324 mm |
| Bottom Bracket Height | 268 mm |
| Front Center | 657 mm |
| Rake | 28 mm |
| Stack | 531 mm |
| Reach | 401 mm |
| Top Tube Length | 575 mm |
| Seat Tube Angle | 70.3 ° |
| Seat Tube Length | 468 mm |
| Head Tube Angle | 67.7 ° |
| Head Tube Length | 250 mm |
| Chainstay Length | 440 mm |
| Wheelbase | 1096 mm |
| Bottom Bracket Drop | 18 mm |
| Standover Height | 655 mm |
| Wheels | 20" |
| Rider Min Height | 120 cm |
About this model
KATU-E 30 is an Orbea E Katu E model. There are 3 e-bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Utility e-bikes
According to our calculations, the average cost of an Utility e-bike that is reliable is 3636$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Utility e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2023 and its price was 2918$. In conclusion, this e-bike price is 24.61% smaller than the price of the average Utility e-bike.
Overview of components
Wheels size
As for the wheels, Orbea KATU-E 30 2023, has a 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The KATU-E 30 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
