Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour X1
-
Groupset Deore -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery BOSCH Performance 500Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 166cm
MD
164cm - 176cm
LG
174cm - 186cm
XL
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Keram 2019, Hydroformed Alloy 6061, Hide out battery technology, bottle cage and dual battery compatible and hidden kickstand compatible
Suspension Fork
SR Suntour X1 Coil LO 100mm QR
Drivetrain
Rear Derailleur
Shimano Deore M5120 SGS Shadow Plus
Shift Levers
Shimano Deore M4100
Cassette
Shimano CS-M4100 11-46t 10-Speed
Crank
PW EB04-NW32 G4
Chain
KMC e10 Turbo Silver
Pedals
VP-537 Black
Wheels
Rims
Alloy, Tubeless, 29", 29c, 32H
Tires
Kenda K1153 2.35" 30TPI
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Alloy, 7º
Handlebar
Alloy, 31.8mm, Flat, 740mm, Sweep 9
Seat
Saddle
Selle Royal 2077 DRN
Seatpost
Alloy, 31.6mm, Setback 0
Motor & Battery
Motor
BOSCH Performance CX Cruise BDU450CX
Battery
BOSCH Performance 500Wh
Charger
Compact Charger 2A (100-240V) Worldwide
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.69 mm | 1.696 mm | 1.639 mm | 1.749 mm |
| Bottom Bracket Height | 307 mm | 313 mm | 313 mm | 313 mm |
| Front Center | 640 mm | 681 mm | 705 mm | 742 mm |
| Rake | 42 mm | 51 mm | 51 mm | 51 mm |
| Trail | 103 mm | 99 mm | 92 mm | 120 mm |
| Stack | 600 mm | 636 mm | 659 mm | 752 mm |
| Reach | 355 mm | 375 mm | 402 mm | 430 mm |
| Top Tube Length | 538 mm | 569 mm | 603 mm | 638.4 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 405 mm | 457 mm | 515 mm |
| Head Tube Angle | 67 ° | 67 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 114 mm | 133 mm | 158 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1112 mm | 1149 mm | 1173 mm | 1210 mm |
| Bottom Bracket Drop | 43 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 798 mm | 825 mm | 861 mm | 893 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 195 cm |
