Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork Suntour XCM -
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey 20 6061 Aluminum 2021, 135x9 QR, Post Mount Disc Mount, 31,6 Seat Post, Internal Cable Routing, Removable hanger
Suspension Fork
SR Suntour XCM HLO SL Air JR 80mm QR
Drivetrain
Rear Derailleur
Shimano Altus M2000 SGS Shadow
Shift Levers
Shimano SL-M2010
Cassette
Sun Race CSM989 11-36t 9-Speed
Crank
Extra light 32t, 127mm, w/Chainguard
Chain
KMC X9
Chain Guide
Orbea Junior Chainguide
Pedals
VP-229 Black with reflectors
Wheels
Rims
Mach1 Klixx 23c Tubeless Ready
Tires
Schwalbe Rocket Ron Perf Foldable, 20x2.25
Brakes
Brakes
Clarks M2 Hydraulic Disc w/Kids Lever
Cockpit
Stem
Race Face Ride
Handlebar
Alloy, 31.8mm, Riser, 560mm
Seat
Saddle
Selle Royal Vivo Junior
Seatpost
OC Mountain Control MC21, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | U |
|---|---|
| Stack Reach Ratio | 1.388 mm |
| Bottom Bracket Height | 248 mm |
| Front Center | 555 mm |
| Rake | 40 mm |
| Stack | 447 mm |
| Reach | 322 mm |
| Top Tube Length | 450 mm |
| Seat Tube Angle | 74 ° |
| Seat Tube Length | 257 mm |
| Head Tube Angle | 66 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 350 mm |
| Wheelbase | 904 mm |
| Bottom Bracket Drop | 23 mm |
| Standover Height | 505 mm |
| Wheels | 20" |
