Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork Suntour XCR Air -
Groupset CUES -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
U
125cm - 150cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey 24 6061 Aluminum 2021, 135x9 QR, Post Mount Disc Mount, 31,6 Seat Post, Internal Cable Routing, Removable hanger.
Suspension Fork
SR Suntour XCR LO Air 80mm QR
Drivetrain
Rear Derailleur
Shimano Cues U4000 GS Shadow
Shift Levers
Shimano Cues SL-U4000
Cassette
Shimano CS-LG300 11-46t 9-Speed
Crank
Extra light 32t, 152mm, w/Chainguard
Chain
KMC eGlide
Chain Guide
Orbea Junior Chainguide
Pedals
VP-229 Black with reflectors
Wheels
Rims
Mach1 Klixx 23c Tubeless Ready
Tires
Schwalbe Rocket Ron Perf Foldable, 24x2.35
Brakes
Brakes
Clarks M2 Hydraulic Disc w/Kids Lever
Cockpit
Stem
Race Face Ride
Handlebar
Alloy, 31.8mm, Riser, 560mm
Grips
OC Lock On
Headset
VP-Z104PD 1-1/8" Semi-Cartridge
Seat
Saddle
Selle Royal Vivo Junior
Seatpost
OC Mountain Control MC21, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | U |
|---|---|
| Stack Reach Ratio | 1.421 mm |
| Bottom Bracket Height | 288 mm |
| Front Center | 627 mm |
| Rake | 40 mm |
| Stack | 520 mm |
| Reach | 366 mm |
| Top Tube Length | 515 mm |
| Seat Tube Angle | 74 ° |
| Seat Tube Length | 300 mm |
| Head Tube Angle | 66 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 395 mm |
| Wheelbase | 1019 mm |
| Bottom Bracket Drop | 35 mm |
| Standover Height | 593 mm |
| Wheels | 24" |
| Rider Min Height | 125 cm |
| Rider Max Height | 150 cm |
