Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
U
125cm - 150cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey 24 6061 Aluminum 2021, 135x9 QR, Post Mount Disc Mount, 31,6 Seat Post, Internal Cable Routing, Removable hanger.
Suspension Fork
Orbea Laufey 24 6061 Aluminum 2021, 100x9 QR, Post Mount Disc Mount, Mini Fender ready
Drivetrain
Rear Derailleur
Shimano Deore M5120 SGS Shadow Plus
Shift Levers
Shimano Deore M4100
Cassette
Sun Race 11-42t 10-Speed
Crank
Extra light 32t, 152mm, w/Chainguard
Chain
KMC X10
Chain Guide
Orbea Junior Chainguide
Pedals
VP-229 Black with reflectors
Wheels
Rims
Alloy, 24", 36H
Tires
Kenda Booster K1277 24x2.20" 30TPI
Brakes
Brakes
Shimano MT410 Hydraulic Disc
Cockpit
Stem
Race Face Ride
Handlebar
Alloy, 31.8mm, Riser, 560mm
Headset
VP-Z104PD 1-1/8" Semi-Cartridge
Seat
Saddle
Selle Royal Vivo Junior
Seatpost
Digit Alloy, 31,6mm, 300mm, Setback 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | U |
|---|---|
| Stack Reach Ratio | 1.421 mm |
| Bottom Bracket Height | 288 mm |
| Front Center | 627 mm |
| Rake | 40 mm |
| Stack | 520 mm |
| Reach | 366 mm |
| Top Tube Length | 515 mm |
| Seat Tube Angle | 74 ° |
| Seat Tube Length | 300 mm |
| Head Tube Angle | 66 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 395 mm |
| Wheelbase | 1019 mm |
| Bottom Bracket Drop | 35 mm |
| Standover Height | 593 mm |
| Wheels | 24" |
| Rider Min Height | 125 cm |
| Rider Max Height | 150 cm |
