Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Marzocchi Bomber Z2
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey 27,5 6061 Aluminum Triple Butted 2021, Tapered head tube, Thru axle 12x148mm Boost, Post Mount Disc Mount, 31,6 Seat Post, Internal Cable Routing, Removable hanger, ISCG 05.
Suspension Fork
Marzocchi Bomber Z2 120 QR15x110
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS Shadow Plus
Shift Levers
Shimano Deore M6100
Cassette
Sun Race 11-51t 12-Speed
Crank
Forged alloy, 32t, Boost
Chain
KMC X12
Chain Guide
Orbea Junior Chainguide
Pedals
VP-229 Black with reflectors
Wheels
Rims
Mach1 Klixx 23c Tubeless Ready
Tires
Schwalbe Nobby Nic Perf, 27.5x2.35 TwinSkin TLR
Brakes
Brakes
Clarks M2 Hydraulic Disc w/Kids Lever
Cockpit
Stem
Race Face Ride
Handlebar
Alloy, 31.8mm, Flat, 720mm
Grips
OC Lock On
Seat
Saddle
Selle Royal Vivo Sport Men 145 x 269mm
Seatpost
OC Mountain Control MC21, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | U |
|---|---|
| Stack Reach Ratio | 1.476 mm |
| Bottom Bracket Height | 315 mm |
| Front Center | 681 mm |
| Rake | 44 mm |
| Trail | 114 mm |
| Stack | 574 mm |
| Reach | 389 mm |
| Top Tube Length | 543 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 343 mm |
| Head Tube Angle | 65.5 ° |
| Head Tube Length | 95 mm |
| Chainstay Length | 425 mm |
| Wheelbase | 1102 mm |
| Bottom Bracket Drop | 43 mm |
| Standover Height | 636 mm |
| Wheels | 27" |
