Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour MOBIE
-
Groupset CUES -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch Powertube 600Wh Horizontal BBP3860 -
Drivetrain 1 × 11 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Muga 2026, Hydroformed Alloy 6061, OLD 148 RD/IGH, Orbea cockpit and equipment ecosystem, w/ Custom Kickstand, Carrier compatible.
Suspension Fork
SR Suntour Mobie34 120mm Air Q15x110
Rear Shock
Fox Float Performance Trunnion 2-Pos custom tune 165x42.5mm
Drivetrain
Rear Derailleur
Shimano Cues U6000 GS Shadow
Shift Levers
Shimano Cues SL-U6000
Cassette
Shimano CS-LG400 11-50t 11-Speed
Crank
Alloy BDU37/38 42t
Chain
KMC eGlide
Pedals
VP-892 Black with reflectors
Wheels
Rims
Alloy, 26c, 32H
Tires
Schwalbe Johnny Watts LR, 60-584, Reflective Tape
Brakes
Brakes
Shimano MT420 Hydraulic Disc
Cockpit
Handlebar
Orbea Urban, Integ. light, Backsweep 9, Rise 30, Width 760
Seat
Saddle
Selle Royal Vivo Ergo
Seatpost
OC Mountain Control MC22, 31.6mm, Dropper
Motor & Battery
Motor
Bosch Performance Line CX BDU3843
Battery
Bosch Powertube 600Wh Horizontal BBP3860
Remote
Bosch Mini Remote BRC3300
Charger
Bosch Charger 4A (230V) BPC3400
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.482 mm | 1.415 mm | 1.364 mm | 1.325 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 748 mm | 784 mm | 813 mm | 844 mm |
| Rake | 36 mm | 37 mm | 36 mm | 36 mm |
| Trail | 115 mm | 114 mm | 115 mm | 115 mm |
| Stack | 652 mm | 665 mm | 675 mm | 689 mm |
| Reach | 440 mm | 470 mm | 495 mm | 520 mm |
| Top Tube Length | 602.5 mm | 636 mm | 663.3 mm | 691.7 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 415 mm | 430 mm | 450 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 130 mm | 145 mm | 155 mm | 170 mm |
| Chainstay Length | 466 mm | 466 mm | 466 mm | 466 mm |
| Wheelbase | 1212 mm | 1248 mm | 1277 mm | 1308 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 779 mm | 785 mm | 787 mm | 793 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
