Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX 16 6061 Aluminum 2021, 113x9 QR (1 speed), V-Brake, 27,2 Seat Post, Internal Cable Routing, Central kick stand compatible.
Suspension Fork
Orbea MX 16 6061 Aluminum 2021, 100x9 QR, V-Brake, Mini Fender ready
Drivetrain
Cassette
18t
Crank
Alloy, 32t, 102mm
Chain
KMC Single-Speed
Chain Guide
Hebie Chainlooper
Pedals
VP-229 Black with reflectors
Wheels
Rims
Alloy, 16", 16H
Tires
Kenda 879 16x1,75" Reflective Logo
Brakes
Brakes
Junior alloy V-brake
Brake Levers
Junior V-Brake lever, alloy body and alloy lever, with reach adjustment
Cockpit
Handlebar
Orbea Alu integrated cockpit 450mm
Headset
VP-Z104PD 1-1/8" Semi-Cartridge
Seat
Saddle
DDK DK16V 216x140mm w/handle
Seatpost
Digit Alloy, 27.2mm, 250mm, Setback 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | U |
|---|---|
| Stack Reach Ratio | 1.147 mm |
| Bottom Bracket Height | 185 mm |
| Front Center | 440 mm |
| Rake | 25 mm |
| Stack | 328 mm |
| Reach | 286 mm |
| Top Tube Length | 386 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 205 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 295 mm |
| Wheelbase | 734 mm |
| Bottom Bracket Drop | 15 mm |
| Standover Height | 379 mm |
| Wheels | 16" |
