Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Altus -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX 20 6061 Aluminum 2021, 135x9 QR, V-Brake + IS Disc Mount, 27,2 Seat Post, Internal Cable Routing, Central kickstand compatible, removable hanger, Fender and Carrier ready.
Suspension Fork
Orbea MX 20 6061 Aluminum 2021, 100x9 QR, V-Brake, Mini + Long Fender ready
Drivetrain
Rear Derailleur
Shimano Altus M310
Shift Levers
Shimano SL-M315
Cassette
Sun Race CSM66 11-34t 8-Speed
Crank
Extra light 32t, 127mm, w/Chainguard
Chain
KMC X8
Chain Guide
Orbea Junior Chainguide
Pedals
VP-229 Black with reflectors
Wheels
Rims
Alloy, 20", 36H
Tires
Kenda Booster K1277 20x2.20" 30TPI
Brakes
Brakes
Junior alloy V-brake
Brake Levers
Junior V-Brake lever, alloy body and alloy lever, with reach adjustment
Cockpit
Handlebar
Orbea Alu integrated cockpit 540mm
Headset
VP-Z104PD 1-1/8" Semi-Cartridge
Seat
Saddle
DDK D2005 237x141mm
Seatpost
Digit Alloy, 27.2mm, 250mm, Setback 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | U |
|---|---|
| Stack Reach Ratio | 1.325 mm |
| Bottom Bracket Height | 236 mm |
| Front Center | 519 mm |
| Rake | 40 mm |
| Stack | 424 mm |
| Reach | 320 mm |
| Top Tube Length | 450 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 257 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 345 mm |
| Wheelbase | 863 mm |
| Bottom Bracket Drop | 18 mm |
| Standover Height | 491 mm |
| Wheels | 20" |
