Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Acera -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX 20 6061 Aluminum 2024, 135x9 QR, Post Mount Disc Mount, 27,2 Seat Post, Internal Cable Routing, Central kickstand compatible, removable hanger, Fender and Carrier ready.
Suspension Fork
Orbea MX 20 6061 Aluminum 2024, 100x9 QR, Post Mount Disc Mount
Drivetrain
Rear Derailleur
Shimano Acera M3020
Shift Levers
Shimano SL-M315
Cassette
Shimano CS-HG400 11-40t 8-Speed
Crank
Extra light 32t, 127mm, w/Chainguard
Chain
KMC X8
Chain Guide
Orbea Junior Chainguide
Pedals
VP-229 Black with reflectors
Wheels
Rims
Alloy, 20", 36H
Tires
Kenda Booster K1277 20x2.20" 30TPI
Brakes
Brakes
Clarks M2 Hydraulic Disc w/Kids Lever
Cockpit
Handlebar
Orbea Alu integrated cockpit 540mm
Seat
Saddle
Ddk D2005 237x141mm
Seatpost
Alloy 27.2x250mm Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | U |
|---|---|
| Stack Reach Ratio | 1.303 mm |
| Bottom Bracket Height | 234 mm |
| Front Center | 509 mm |
| Rake | 40 mm |
| Stack | 404 mm |
| Reach | 310 mm |
| Top Tube Length | 426 mm |
| Seat Tube Angle | 74 ° |
| Seat Tube Length | 257 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 345 mm |
| Wheelbase | 853 mm |
| Bottom Bracket Drop | 20 mm |
| Standover Height | 481 mm |
| Wheels | 20" |
